Gabion boxes, rockfall nets, chain link fences, noise barriers — ISO/CE certified, factory-direct.
Angu Wire Mesh offers a complete range of wire mesh products for construction, mining, landscaping, and military applications. All products are ISO 9001:2015 and CE certified.
Common questions about our wire mesh products, specifications, and ordering.
Portable temporary fence panel, 2.1m x 2.4m, welded mesh 50mm x 2.5mm galvanized. Stand-alone with concrete bases. For construction sites, events, crowd control. MOQ 50 panels, 5-10 day delivery.
Temporary isolation fence panels are freestanding modular fencing units designed for rapid deployment and removal without permanent installation. Each panel is a complete unit — mesh welded to a steel frame, paired with a concrete base — that can be positioned by two workers in minutes.
## Construction
- **Panel**: Welded wire mesh (50mm x 50mm opening, 2.5mm wire) welded to a tubular steel frame - **Frame**: 32mm OD x 1.5mm wall thickness steel pipe, galvanized - **Feet/Base**: Concrete block (600mm x 100mm x 100mm) with welded steel receiver sleeve. Alternative: steel plate base for indoor use. - **Connection**: Panels couple via industry-standard male/female hook-and-eye clips. No tools needed. - **Stability**: Concrete base weight (28 kg) provides wind resistance up to 80 km/h without additional support.
## Key Advantages
- **Zero-Installation**: No digging, no concrete pouring, no post driving. Place and connect. - **Rapid Deployment**: 100m of fencing can be installed by 2 workers in under 2 hours. - **Reusable**: Panels and bases have 10+ year service life. Move site-to-site. - **Ganging**: Panels lock together sequentially. Can form straight runs, corners, and enclosures. - **Wind Resistant**: Concrete bases + low mesh wind load = stable in high winds without guy wires. - **Anti-Climb**: 2.5mm wire in 50mm grid — too small for foothold, too strong for hand bending. - **Portable**: Each panel + base weighs ~35 kg. Two-person lift. Fits in standard pickup truck.
## Technical Specifications
| Parameter | Value | |-----------|-------| | Panel Size | 2.1m (H) x 2.4m (W) | | Mesh Type | Welded wire mesh | | Mesh Opening | 50mm x 50mm | | Wire Diameter | 2.5mm | | Frame | 32mm OD x 1.5mm steel tube, galvanized | | Base | Concrete 600x100x100mm, 28 kg | | Total Weight | ~35 kg per panel (with base) | | Connection | Hook-and-eye clips | | Wind Rating | 80 km/h freestanding | | Finish | Hot-dipped galvanized (frame + mesh) | | Standard | AS 4687, BS EN 13413 |
## Applications
- **Construction Sites**: Site perimeter, hazard zone isolation, material storage - **Events & Concerts**: Crowd channeling, VIP areas, ticketing queues - **Road Works**: Traffic lane separation, pedestrian protection - **Demolition**: Dust containment, debris zone isolation - **Public Safety**: Sinkhole barriers, hazard marking, emergency scene perimeters - **Agricultural**: Temporary livestock enclosures, crop protection - **Industrial**: Equipment isolation during maintenance, laydown area security
## Packaging & Delivery
- **Packaging**: Panels stacked vertically on pallets (10 panels/pallet). Bases palletized separately. - **Container Loading**: 20ft GP ~ 200-300 panels; 40ft HQ ~ 400-600 panels - **Lead Time**: 5-10 days standard; 10-15 days custom - **Shipping**: FOB Tianjin / CIF / DDP
Portable temporary fence panel, 2.1m x 2.4m, welded mesh 50mm x 2.5mm galvanized. Stand-alone with concrete bases. For construction sites, events, crowd control. MOQ 50 panels, 5-10 day delivery.
| Panel Size | 2.1m (H) x 2.4m (W) |
|---|---|
| Mesh Type | Welded wire mesh |
| Mesh Aperture | 50mm x 50mm |
| Wire Diameter | 2.5mm |
| Frame | 32mm OD x 1.5mm steel tube, galvanized |
| Base | Concrete 600x100x100mm, 28 kg |
| Total Weight | ~35 kg per panel (with base) |
| Connection | Hook-and-eye clips |
| Wind Rating | 80 km/h freestanding |
| Finish | Hot-dipped galvanized |
| Standard | AS 4687, BS EN 13413 |
| MOQ | 50 pieces |
FOB Tianjin, per panel
